DB-10NP 10mm Rotary potentiometer
Product Details
| DESCRIPTION: | DB-10NP Rotary potentiometer |
| HOWANG P/N: | DB-10NP |
| MECHANICAL CHARACTERISTIC | 1. Total Rotation angle: 200 ∘± 5 ∘ |
| 2. Rotational Torque: 10 ~ 80 gf.cm | |
| 3. Rotation Stopper Strength：2.0 Kgf.cm Min | |
| 4. Rotational life: Standard Life: 15,000 cycles； | |
| ELECTRICAL CHARACTERISTIC | 1. Total resistance: 1K~1MΩ |
| 2. Resistance taper: A/B/C/D | |
| 3. Rated power: Single unit: 0.07W;Dual unit: 0.03W | |
| 4.Sliding noise:Less than 100 Mv | |
| 5.Insulation resistance: More than 100 MΩ at DC 250 V | |
| 6.Residual Resistance:Less than 20 Ω |
This is an introduction about HOWANG 10mm rotary potentiometer series. We have many sizes and specifications for choice. Please be free to leave us a message below or contact us to learn more technical and price details. Our team will quickly respond within 24 hours.
